CCNA 2 V6.0 Final Exam Answers Option A Questions and Answers

When a customer purchases a Cisco IOS 15.0 software package, what serves as the receipt for that customer and is used to obtain the license as well?

Software Claim Certificate

Unique Device Identifier

Product Activation Key

End User License Agreement

¡ Correcto ! ¡ Incorrecto !

Two employees in the Sales department work different shifts with their laptop computers and share the same Ethernet port in the office. Which set of commands would allow only these two laptops to use the Ethernet port and create violation log entry without shutting down the port if a violation occurs?

switchport mode access
switchport port-security

switchport mode access
switchport port-security maximum 2
switchport port-security mac-address sticky
switchport port-security violation protect

switchport mode access
switchport port-security
switchport port-security maximum 2
switchport port-security mac-address sticky
switchport port-security violation restrict

switchport mode access
switchport port-security maximum 2
switchport port-security mac-address sticky

¡ Correcto ! ¡ Incorrecto !

A Cisco Catalyst switch has been added to support the use of multiple VLANs as part of an enterprise network. The network technician finds it necessary to clear all VLAN information from the switch in order to incorporate a new network design. What should the technician do to accomplish this task?

Erase the running configuration and reboot the switch.

Delete the startup configuration and the vlan.dat file in the flash memory of the switch and reboot the switch.

Erase the startup configuration and reboot the switch.

Delete the IP address that is assigned to the management VLAN and reboot the switch.

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. Based on the output that is shown, what type of NAT has been implemented?

static NAT with one entry

PAT using an external interface

dynamic NAT with a pool of two public IP addresses

static NAT with a NAT pool

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. Assuming that the routing tables are up to date and no ARP messages are needed, after a packet leaves H1, how many times is the L2 header rewritten in the path to H2?

¡ Correcto ! ¡ Incorrecto !

The computers used by the network administrators for a school are on the 10.7.0.0/27 network. Which two commands are needed at a minimum to apply an ACL that will ensure that only devices that are used by the network administrators will be allowed Telnet access to the routers? (Choose two.)

Por favor, selecciona 2 respuestas correctas

access-list 5 permit 10.7.0.0 0.0.0.31

access-list 5 deny any

access-class 5 in

access-list standard VTY
permit 10.7.0.0 0.0.0.127

ip access-group 5 out

ip access-group 5 in

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. An administrator is trying to configure PAT on R1, but PC-A is unable to access the Internet. The administrator tries to ping a server on the Internet from PC-A and collects the debugs that are shown in the exhibit. Based on this output, what is most likely the cause of the problem?

The NAT source access list matches the wrong address range.

The inside global address is not on the same subnet as the ISP.

The inside and outside NAT interfaces have been configured backwards.

The address on Fa0/0 should be 64.100.0.1.

¡ Correcto ! ¡ Incorrecto !

A network administrator reviews the routing table on the router and sees a route to the destination network 172.16.64.0/18 with a next-hop IP address of 192.168.1.1. What are two descriptions of this route? (Choose two.)

Por favor, selecciona 2 respuestas correctas

ultimate route

default route

parent route

supernet route

level 2 child route

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. A network administrator is configuring a router as a DHCPv6 server. The administrator issues a show ipv6 dhcp pool command to verify the configuration. Which statement explains the reason that the number of active clients is 0?

No clients have communicated with the DHCPv6 server yet.

The state is not maintained by the DHCPv6 server under stateless DHCPv6 operation.

The IPv6 DHCP pool configuration has no IPv6 address range specified.

The default gateway address is not provided in the pool.

¡ Correcto ! ¡ Incorrecto !

What VLANs are allowed across a trunk when the range of allowed VLANs is set to the default value?

All VLANs will be allowed across the trunk.

Only the native VLAN will be allowed across the trunk.

Only VLAN 1 will be allowed across the trunk.

The switches will negotiate via VTP which VLANs to allow across the trunk.

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. Currently router R1 uses an EIGRP route learned from Branch2 to reach the 10.10.0.0/16 network. Which floating static route would create a backup route to the 10.10.0.0/16 network in the event that the link between R1 and Branch2 goes down?

ip route 10.10.0.0 255.255.0.0 Serial 0/0/0 100

ip route 10.10.0.0 255.255.0.0 209.165.200.225 100

ip route 10.10.0.0 255.255.0.0 209.165.200.226 100

ip route 10.10.0.0 255.255.0.0 209.165.200.225 50

¡ Correcto ! ¡ Incorrecto !

What is the reason why the DHCPREQUEST message is sent as a broadcast during the DHCPv4 process?

for routers to fill their routing tables with this new information

for hosts on other subnets to receive the information

to notify other hosts not to request the same IP address

to notify other DHCP servers on the subnet that the IP address was leased

¡ Correcto ! ¡ Incorrecto !

Which set of commands will configure a router as a DHCP server that will assign IPv4 addresses to the 192.168.100.0/23 LAN while reserving the first 10 and the last addresses for static assignment?

ip dhcp excluded-address 192.168.100.1 192.168.100.10
ip dhcp excluded-address 192.168.101.254
ip dhcp pool LAN-POOL-100
network 192.168.100.0 255.255.254.0
default-router 192.168.100.1

dhcp pool LAN-POOL-100
ip dhcp excluded-address 192.168.100.1 192.168.100.9
ip dhcp excluded-address 192.168.100.254
network 192.168.100.0 255.255.254.0
default-router 192.168.101.1

ip dhcp excluded-address 192.168.100.1 192.168.100.9
ip dhcp excluded-address 192.168.101.254
ip dhcp pool LAN-POOL-100
ip network 192.168.100.0 255.255.254.0
ip default-gateway 192.168.100.1

ip dhcp excluded-address 192.168.100.1 192.168.100.10
ip dhcp excluded-address 192.168.100.254
ip dhcp pool LAN-POOL-100
network 192.168.100.0 255.255.255.0
ip default-gateway 192.168.100.1

¡ Correcto ! ¡ Incorrecto !

A router has used the OSPF protocol to learn a route to the 172.16.32.0/19 network. Which command will implement a backup floating static route to this network?

ip route 172.16.0.0 255.255.224.0 S0/0/0 100

ip route 172.16.0.0 255.255.240.0 S0/0/0 200

ip route 172.16.32.0 255.255.224.0 S0/0/0 200

ip route 172.16.32.0 255.255.0.0 S0/0/0 100

¡ Correcto ! ¡ Incorrecto !

In what situation would a Layer 2 switch have an IP address configured?

when the Layer 2 switch is the default gateway of user traffic

when the Layer 2 switch is using a routed port

when the Layer 2 switch needs to be remotely managed

when the Layer 2 switch needs to forward user traffic to another device

¡ Correcto ! ¡ Incorrecto !

What are three functions provided by the syslog service? (Choose three.)

Por favor, selecciona 3 respuestas correctas

to provide statistics on packets that are flowing through a Cisco device

to provide traffic analysis

to periodically poll agents for data

to select the type of logging information that is captured

to specify the destinations of captured messages

to gather logging information for monitoring and troubleshooting

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. Which route was configured as a static route to a specific network using the next-hop address?

C 172.16.2.0/24 is directly connected, Serial0/0/0

S 192.168.2.0/24 is directly connected, Serial 0/0/0

S 0.0.0.0/0 [1/0] via 172.16.2.2

S 192.168.2.0/24 [1/0] via 172.16.2.2

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. An administrator is examining the message in a syslog server. What can be determined from the message?

This is an alert message for which immediate action is needed.

This is an error message for which warning conditions exist.

This is an error message that indicates the system is unusable.

This is a notification message for a normal but significant condition.

¡ Correcto ! ¡ Incorrecto !

Which information does a switch use to populate the MAC address table?

the source and destination MAC addresses and the incoming port

the source MAC address and the outgoing port

the source MAC address and the incoming port

the source and destination MAC addresses and the outgoing port

the destination MAC address and the incoming port

the destination MAC address and the outgoing port

¡ Correcto ! ¡ Incorrecto !

Match each borderless switched network principle to its description. (Not all options are used.)

Place the options in the following order:
hierarchical
modularity
resiliency
– not scored –
flexibility

¡ Correcto ! ¡ Incorrecto !

Compared with dynamic routes, what are two advantages of using static routes on a router? (Choose two.)

Por favor, selecciona 2 respuestas correctas

They automatically switch the path to the destination network when the topology changes.

They take less time to converge when the network topology changes.

They improve network security.

They use fewer router resources.

They improve the efficiency of discovering neighboring networks.

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. A network administrator is configuring inter-VLAN routing on a network. For now, only one VLAN is being used, but more will be added soon. What is the missing parameter that is shown as the highlighted question mark in the graphic?

It identifies the native VLAN number.

It identifies the type of encapsulation that is used.

It identifies the VLAN number.

It identifies the subinterface.

It identifies the number of hosts that are allowed on the interface.

¡ Correcto ! ¡ Incorrecto !

A network administrator is configuring a new Cisco switch for remote management access. Which three items must be configured on the switch for the task? (Choose three.)

Por favor, selecciona 3 respuestas correctas

default VLAN

vty lines

IP address

VTP domain

default gateway

loopback address

¡ Correcto ! ¡ Incorrecto !

A network technician has been asked to secure all switches in the campus network. The security requirements are for each switch to automatically learn and add MAC addresses to both the address table and the running configuration. Which port security configuration will meet these requirements?

dynamic secure MAC addresses

auto secure MAC addresses

static secure MAC addresses

sticky secure MAC addresses

¡ Correcto ! ¡ Incorrecto !

A network engineer has created a standard ACL to control SSH access to a router. Which command will apply the ACL to the VTY lines?

access-list 110 in

access-class 11 in

access-group 11 in

access-list 11 in

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. Which statement shown in the output allows router R1 to respond to stateless DHCPv6 requests?

dns-server 2001:DB8:8::8

ipv6 nd other-config-flag

prefix-delegation 2001:DB8:8::/48 00030001000E84244E70

ipv6 dhcp server LAN1

ipv6 unicast-routing

¡ Correcto ! ¡ Incorrecto !

What network prefix and prefix-length combination is used to create a default static route that will match any IPv6 destination?

::1/64

::/0

::/128

FFFF::/128

¡ Correcto ! ¡ Incorrecto !

Which switching method drops frames that fail the FCS check?

ingress port buffering

borderless switching

store-and-forward switching

cut-through switching

¡ Correcto ! ¡ Incorrecto !

A network administrator is configuring port security on a Cisco switch. When a violation occurs, which violation mode that is configured on an interface will cause packets with an unknown source address to be dropped with no notification sent?

off

restrict

protect

shutdown

¡ Correcto ! ¡ Incorrecto !

What is a characteristic of the distribution layer in the three layer hierarchical model?

distributes access to end users

provides access to the rest of the network through switching, routing, and network access policies

acts as the backbone for the network, aggregating and distributing network traffic throughout the campus

represents the network edge

¡ Correcto ! ¡ Incorrecto !

Which command, when issued in the interface configuration mode of a router, enables the interface to acquire an IPv4 address automatically from an ISP, when that link to the ISP is enabled?

ip address dhcp

service dhcp

ip helper-address

ip dhcp pool

¡ Correcto ! ¡ Incorrecto !

Which statement is correct about Ethernet switch frame forwarding decisions?

Unicast frames are always forwarded regardless of the destination MAC address.

Only frames with a broadcast destination address are forwarded out all active switch ports.

Cut-through frame forwarding ensures that invalid frames are always dropped.

Frame forwarding decisions are based on MAC address and port mappings in the CAM table.

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. What protocol should be configured on SW-A Port 0/1 if it is to send traffic from multiple VLANs to switch SW-B?

Rapid Spanning Tree

ARP

RIP v2

Spanning Tree

IEEE 802.1Q

¡ Correcto ! ¡ Incorrecto !

Match the router memory type that provides the primary storage for the router feature. (Not all options are used.)

Place the options in the following order.

— not scored —
full operating system -> flash
limited operating system -> ROM
routing table -> RAM
startup configuration file -> NVRAM

¡ Correcto ! ¡ Incorrecto !

Which type of traffic is designed for a native VLAN?

management

user-generated

tagged

untagged

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. What is the administrative distance value that indicates the route for R2 to reach the 10.10.0.0/16 network?

20512256

¡ Correcto ! ¡ Incorrecto !

A network administrator adds the default-information originate command to the configuration of a router that uses RIP as the routing protocol. What will result from adding this command?

The router will be reset to the default factory information.

The router will not forward routing information that is learned from other routers.

The router will propagate a static default route in its RIP updates, if one is present.

The router will only forward packets that originate on directly connected networks.

¡ Correcto ! ¡ Incorrecto !

Employees of a company connect their wireless laptop computers to the enterprise LAN via wireless access points that are cabled to the Ethernet ports of switches. At which layer of the three-layer hierarchical network design model do these switches operate?

distribution

data link

physical

core

access

¡ Correcto ! ¡ Incorrecto !

Which type of static route is configured with a greater administrative distance to provide a backup route to a route learned from a dynamic routing protocol?

floating static route

standard static route

default static route

summary static route

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. The network administrator enters these commands into the R1 router:

R1# copy running-config tftp
Address or name of remote host [ ]?

When the router prompts for an address or remote host name, what IP address should the administrator enter at the prompt?

192.168.11.254

192.168.10.2

192.168.9.254

192.168.11.252

192.168.10.1

¡ Correcto ! ¡ Incorrecto !

Which two factors are important when deciding which interior gateway routing protocol to use? (Choose two.)

Por favor, selecciona 2 respuestas correctas

the autonomous system that is used

speed of convergence

campus backbone architecture

scalability

ISP selection

¡ Correcto ! ¡ Incorrecto !

A college marketing department has a networked storage device that uses the IP address 10.18.7.5, TCP port 443 for encryption, and UDP port 4365 for video streaming. The college already uses PAT on the router that connects to the Internet. The router interface has the public IP address of 209.165.200.225/30. The IP NAT pool currently uses the IP addresses ranging from 209.165.200.228-236. Which configuration would the network administrator add to allow this device to be accessed by the marketing personnel from home?

ip nat inside source static tcp 10.18.7.5 443 209.165.200.225 443
ip nat inside source static udp 10.18.7.5 4365 209.165.200.225 4365

No additional configuration is necessary

ip nat inside source static tcp 209.165.200.225 443 10.18.7.5 443
ip nat inside source static udp 209.165.200.225 4365 10.18.7.5 4365

ip nat pool mktv 10.18.7.5 10.18.7.5

ip nat outside source static 10.18.7.5 209.165.200.225

¡ Correcto ! ¡ Incorrecto !

A network engineer is interested in obtaining specific information relevant to the operation of both distribution and access layer Cisco devices. Which command provides common information relevant to both types of devices?

show mac-address-table

show port-security

show ip interface

show cdp neighbors

show ip protocols

¡ Correcto ! ¡ Incorrecto !

Which statement describes a route that has been learned dynamically?

It has an administrative distance of 1.

It is unaffected by changes in the topology of the network.

It is automatically updated and maintained by routing protocols.

It is identified by the prefix C in the routing table.

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. Which two statements are correct based on the output as shown in the exhibit? (Choose two.)

Por favor, selecciona 2 respuestas correctas

The host with the address 209.165.200.235 will respond to requests by using a source address of 192.168.10.10.

Traffic with the destination address of a public web server will be sourced from the IP of 192.168.1.10.

The output is the result of the show ip nat translations command.

The host with the address 209.165.200.235 will respond to requests by using a source address of 209.165.200.235.

The output is the result of the show ip nat statistics command.

¡ Correcto ! ¡ Incorrecto !

Which two statements are correct if a configured NTP master on a network cannot reach any clock with a lower stratum number? (Choose two.)

Por favor, selecciona 2 respuestas correctas

Other systems will be willing to synchronize to that master using NTP.

The NTP master will lower its stratum number.

The NTP master will be the clock with 1 as its stratum number.

The NTP master will claim to be synchronized at the configured stratum number.

An NTP server with a higher stratum number will become the master.

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. Which highlighted value represents a specific destination network in the routing table?

0.0.0.0

791

172.16.100.2

110

172.16.100.64

¡ Correcto ! ¡ Incorrecto !

Match the description to the correct VLAN type. (Not all options are used.)

configured to carry user generated traffic -> data VLANs
all switch ports are assigner to this WLAN after initial bootup of the switch -> default VLAN
carries untagged traffic -> native VLAN
an IP address and subnet mask are assigned to this VLAN, allowing the switch to be accessed by HTTP, Telnet, SSH or SNMP -> management VLAN

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. NAT is configured on Remote and Main. The PC is sending a request to the web server. What IPv4 address is the source IP address in the packet between Main and the web server?

209.165.200.245

172.16.1.10

10.130.5.76

192.0.2.1

209.165.200.226

203.0.113.5

¡ Correcto ! ¡ Incorrecto !

A network administrator is designing an ACL. The networks 192.168.1.0/25, 192.168.0.0/25, 192.168.0.128/25, 192.168.1.128/26, and 192.168.1.192/26 are affected by the ACL. Which wildcard mask, if any, is the most efficient to use when specifying all of these networks in a single ACL permit entry?

0.0.0.127

0.0.255.255

0.0.1.255

0.0.0.255

¡ Correcto ! ¡ Incorrecto !

Refer to the exhibit. A network administrator has configured R2 for PAT. Why is the configuration incorrect?

The static NAT entry is missing.

The ACL does not define the list of addresses to be translated.

NAT-POOL2 is bound to the wrong ACL.

The overload keyword should not have been applied.

¡ Correcto ! ¡ Incorrecto !

CCNA 2 v6 Final Exam Answers Option A

Final Score

Congratulations, you have completed the Final Exam Answers Option A of CCNA 2! Tell us your rating!

6 Comentarios

Nena Vega dice:

mayo 9, 2018 a las 1:07 pm

Gracias Alex!!!

Responder
1. Alex Walton dice:

  mayo 9, 2018 a las 5:18 pm

  Gracias a ti! Éxitos! 😉

  Responder
Angelo dice:

julio 1, 2019 a las 9:03 am

Hi,
All these questions are on the final exam? Are updated?

Thanks,

Responder
1. Alex Walton dice:

  noviembre 19, 2019 a las 10:03 pm

  Yes!

  Responder
Conrad Nomikos dice:

enero 8, 2020 a las 2:34 pm

At least two question have the question wrong, for the right answer.

Responder
1. Alex Walton dice:

  enero 9, 2020 a las 1:12 am

  What are they? Can you help me check again?

  Responder

Deja una respuesta Cancelar la respuesta

Este sitio usa Akismet para reducir el spam. Aprende cómo se procesan los datos de tus comentarios.

CCNA2 v7 SRWE | Práctica Final Respuestas Preguntas

CCNA3 v7 ENSA | Examen Final Respuestas Preguntas

CCNA3 v7 ENSA | Módulos 13 – 14 Respuestas Preguntas

CCNA 2 Final Exam Answers Option A

Cisco CCNA 2 Simulation v6.0 Test Final Exam Option A

CCNA 1 Chapter 2 Exam Answers

CCNA 2 V6.0 Final Exam Answers Option A Questions and Answers

When a customer purchases a Cisco IOS 15.0 software package, what serves as the receipt for that customer and is used to obtain the license as well?

A Cisco Catalyst switch has been added to support the use of multiple VLANs as part of an enterprise network. The network technician finds it necessary to clear all VLAN information from the switch in order to incorporate a new network design. What should the technician do to accomplish this task?

Refer to the exhibit. Based on the output that is shown, what type of NAT has been implemented?

Refer to the exhibit. Assuming that the routing tables are up to date and no ARP messages are needed, after a packet leaves H1, how many times is the L2 header rewritten in the path to H2?

The computers used by the network administrators for a school are on the 10.7.0.0/27 network. Which two commands are needed at a minimum to apply an ACL that will ensure that only devices that are used by the network administrators will be allowed Telnet access to the routers? (Choose two.)

A network administrator reviews the routing table on the router and sees a route to the destination network 172.16.64.0/18 with a next-hop IP address of 192.168.1.1. What are two descriptions of this route? (Choose two.)

Refer to the exhibit. A network administrator is configuring a router as a DHCPv6 server. The administrator issues a show ipv6 dhcp pool command to verify the configuration. Which statement explains the reason that the number of active clients is 0?

What VLANs are allowed across a trunk when the range of allowed VLANs is set to the default value?

Refer to the exhibit. Currently router R1 uses an EIGRP route learned from Branch2 to reach the 10.10.0.0/16 network. Which floating static route would create a backup route to the 10.10.0.0/16 network in the event that the link between R1 and Branch2 goes down?

What is the reason why the DHCPREQUEST message is sent as a broadcast during the DHCPv4 process?

Which set of commands will configure a router as a DHCP server that will assign IPv4 addresses to the 192.168.100.0/23 LAN while reserving the first 10 and the last addresses for static assignment?

A router has used the OSPF protocol to learn a route to the 172.16.32.0/19 network. Which command will implement a backup floating static route to this network?

In what situation would a Layer 2 switch have an IP address configured?

What are three functions provided by the syslog service? (Choose three.)

Refer to the exhibit. Which route was configured as a static route to a specific network using the next-hop address?

Refer to the exhibit. An administrator is examining the message in a syslog server. What can be determined from the message?

Which information does a switch use to populate the MAC address table?

Match each borderless switched network principle to its description. (Not all options are used.)

Compared with dynamic routes, what are two advantages of using static routes on a router? (Choose two.)

Refer to the exhibit. A network administrator is configuring inter-VLAN routing on a network. For now, only one VLAN is being used, but more will be added soon. What is the missing parameter that is shown as the highlighted question mark in the graphic?

A network administrator is configuring a new Cisco switch for remote management access. Which three items must be configured on the switch for the task? (Choose three.)

A network technician has been asked to secure all switches in the campus network. The security requirements are for each switch to automatically learn and add MAC addresses to both the address table and the running configuration. Which port security configuration will meet these requirements?

A network engineer has created a standard ACL to control SSH access to a router. Which command will apply the ACL to the VTY lines?

Refer to the exhibit. Which statement shown in the output allows router R1 to respond to stateless DHCPv6 requests?

What network prefix and prefix-length combination is used to create a default static route that will match any IPv6 destination?

Which switching method drops frames that fail the FCS check?

A network administrator is configuring port security on a Cisco switch. When a violation occurs, which violation mode that is configured on an interface will cause packets with an unknown source address to be dropped with no notification sent?

What is a characteristic of the distribution layer in the three layer hierarchical model?

Which command, when issued in the interface configuration mode of a router, enables the interface to acquire an IPv4 address automatically from an ISP, when that link to the ISP is enabled?

Which statement is correct about Ethernet switch frame forwarding decisions?

Refer to the exhibit. What protocol should be configured on SW-A Port 0/1 if it is to send traffic from multiple VLANs to switch SW-B?

Match the router memory type that provides the primary storage for the router feature. (Not all options are used.)

Which type of traffic is designed for a native VLAN?

Refer to the exhibit. What is the administrative distance value that indicates the route for R2 to reach the 10.10.0.0/16 network?

A network administrator adds the default-information originate command to the configuration of a router that uses RIP as the routing protocol. What will result from adding this command?

Employees of a company connect their wireless laptop computers to the enterprise LAN via wireless access points that are cabled to the Ethernet ports of switches. At which layer of the three-layer hierarchical network design model do these switches operate?

Which type of static route is configured with a greater administrative distance to provide a backup route to a route learned from a dynamic routing protocol?

Refer to the exhibit. The network administrator enters these commands into the R1 router:R1# copy running-config tftpAddress or name of remote host [ ]?When the router prompts for an address or remote host name, what IP address should the administrator enter at the prompt?

Which two factors are important when deciding which interior gateway routing protocol to use? (Choose two.)

A network engineer is interested in obtaining specific information relevant to the operation of both distribution and access layer Cisco devices. Which command provides common information relevant to both types of devices?

Which statement describes a route that has been learned dynamically?

Refer to the exhibit. Which two statements are correct based on the output as shown in the exhibit? (Choose two.)

Which two statements are correct if a configured NTP master on a network cannot reach any clock with a lower stratum number? (Choose two.)

Refer to the exhibit. Which highlighted value represents a specific destination network in the routing table?

Match the description to the correct VLAN type. (Not all options are used.)

Refer to the exhibit. NAT is configured on Remote and Main. The PC is sending a request to the web server. What IPv4 address is the source IP address in the packet between Main and the web server?

A network administrator is designing an ACL. The networks 192.168.1.0/25, 192.168.0.0/25, 192.168.0.128/25, 192.168.1.128/26, and 192.168.1.192/26 are affected by the ACL. Which wildcard mask, if any, is the most efficient to use when specifying all of these networks in a single ACL permit entry?

Refer to the exhibit. A network administrator has configured R2 for PAT. Why is the configuration incorrect?

CCNA2 v7 SRWE | Práctica Final Respuestas Preguntas

CCNA3 v7 ENSA | Examen Final Respuestas Preguntas

CCNA3 v7 ENSA | Módulos 13 – 14 Respuestas Preguntas

Subscribe

Refer to the exhibit. The network administrator enters these commands into the R1 router:

R1# copy running-config tftp
Address or name of remote host [ ]?

When the router prompts for an address or remote host name, what IP address should the administrator enter at the prompt?
